¶ User
At a Glance
Owner: Sysadmin (+ Security Officer for sessions) · Table:tb_user(+tb_user_profile,tb_user_login_session) · Used by: every*_by_idaudit column in the system · Identity layer — the most-FK'd entity in the platform. Passwords are externalized (thetb_passwordtable was dropped 2026-05-17).
¶ 1. What & Who
The user entity is the identity layer for the entire platform. Every transactional row in every tenant carries created_by_id / updated_by_id / deleted_by_id referencing a row here, so this is the most-foreign-keyed entity in the system. It also feeds RBAC (access-control/application-role), per-BU access (access-control/business-unit-user), and per-location scoping (access-control/user-location).
The entity is split across three platform tables: tb_user (account), tb_user_profile (name/phone/bio/avatar), tb_user_login_session (tokens). Splitting keeps the hot path narrow. The tb_password table was removed on 2026-05-17 — password storage and verification now live in an external identity provider that issues the tokens recorded in tb_user_login_session. The platform schema is therefore credential-free.
Maintained by Sysadmin (accounts) and Security Officer (sessions). Read by every API request (audit + token validation). Password reset / rotation is handled by the external identity provider.
¶ 2. Common Tasks
| Task | Where | Notes |
|---|---|---|
| Create a user account | Platform admin → User Management → New | Sets tb_user row; initial credential provisioning happens in the external identity provider |
| Edit profile (firstname, phone, avatar) | Account → Profile screen | User can self-edit |
| Reset password | External identity provider's flow (e.g. reset email link) | No schema effect on the carmen platform side; subsequent logins simply present a fresh access_token |
| Deactivate account | Set is_active = false |
Login blocked here even if external IdP still issues tokens (server validates is_active) |
| Force logout | Delete tb_user_login_session rows |
Or wait for expired_on to lapse |
| Soft-delete user | Set deleted_at |
FK targets remain valid for historical audit |
¶ 3. Validation & Errors
| Symptom | Cause | Action |
|---|---|---|
| "Username already exists" | App-level uniqueness on non-deleted users | Pick a different username |
| Login rejected unexpectedly | External identity provider rejected the credential or returned an unmapped subject | Investigate at the IdP; the platform schema no longer stores password state |
| "Must accept T&Cs" | is_consent = false |
User must accept to unlock transactional UI |
| Cannot hard-delete user | Audit FKs reference the row | Inactivate or soft-delete instead |
| Forced password change | Driven by the external IdP's rotation policy | Handled outside this schema |
¶ 4. Edge Cases
- Platform role bypass.
super_admin/platform_adminbypass tenant RBAC;security_officermanages credentials;integration_developerexists for service accounts. - Online presence is best-effort.
is_online/socket_idare caches written by the realtime channel — not authoritative for security. - No password history on this side. Past hashes / rotation policy live in the external identity provider. The carmen platform schema only sees the issued token in
tb_user_login_session. - Session uniqueness.
tokenis globally unique so token reuse is detectable.
¶ 5. Data Model (Dev)
Source: platform schema.
¶ 5.1 tb_user
| Field | Prisma Type | Nullable | Description |
|---|---|---|---|
id |
String @db.Uuid |
No | Primary key. Target of every *_by_id FK. |
username |
String @db.VarChar |
No | Login username. |
email |
String @db.VarChar |
No | Login / contact email. |
alias_name |
String? @db.VarChar |
Yes | Optional display alias. |
platform_role |
enum_platform_role |
No | Default user. Coarse platform-wide role. |
is_active |
Boolean? |
Yes | Default false. Account-enabled. |
is_consent |
Boolean? |
Yes | Default false. T&C acceptance. |
socket_id |
String? |
Yes | Live socket id (presence). |
is_online |
Boolean |
No | Default false. Cached presence. |
consent_at |
DateTime? @db.Timestamptz(6) |
Yes | When user accepted T&C. |
| Audit columns | — | Yes | created_*, updated_*, deleted_*. |
enum_platform_role: super_admin, platform_admin, support_manager, support_staff, security_officer, integration_developer, user.
¶ 5.2 tb_user_profile
| Field | Prisma Type | Nullable | Description |
|---|---|---|---|
id |
String @db.Uuid |
No | Primary key. |
user_id |
String? @db.Uuid |
Yes | FK to tb_user. |
firstname / middlename / lastname |
String @db.VarChar(100) |
Mixed | Default "". |
telephone |
String? @db.VarChar(20) |
Yes | Phone. |
bio |
Json? @db.Json |
Yes | Default {}. |
avatar_file_token |
String? @db.VarChar |
Yes | Reference to the user's avatar image in the platform file service (added 2026-05-20). Same file_token pattern as tb_business_unit.logo_file_token and tb_product_image.file_token. |
| Audit columns | — | Yes | created_*, updated_*, deleted_*. |
¶ 5.3 tb_user_login_session
| Field | Prisma Type | Nullable | Description |
|---|---|---|---|
id / user_id |
String @db.Uuid |
No | Keys. |
token |
String @db.VarChar |
No | Token string. |
token_type |
enum_token_type |
No | Default access_token. |
expired_on |
DateTime @db.Timestamptz(6) |
No | Default now() + '1 day'. |
Constraints: @@unique([token]). enum_token_type: access_token, refresh_token.
¶ 6. Business Rules
- Uniqueness. App-level:
usernameandemailglobally unique among non-deleted users. - Deletion guards. Users referenced by audit FKs cannot be hard-deleted — inactivate instead.
- Consent.
is_consent = truerequired before transactional UI is unlocked. - Password rotation. Owned by the external identity provider — no rows on the carmen platform side.
- Session lifecycle. Short-lived; refresh deleted on logout; reuse detectable via unique
token. - Online presence. Caches only; not authoritative for security decisions.
¶ 7. Cross-References
- access-control/application-role — RBAC join.
- access-control/business-unit-user — per-BU access.
- access-control/user-location — tenant-side per-location scope.
- access-control/permission — granted transitively via roles.
- master-data/business-unit — every BU is audited by
tb_user. - All transactional modules — every
*_by_idaudit column.
¶ 8. References
- Prisma:
../carmen-turborepo-backend-v2/packages/prisma-shared-schema-platform/prisma/schema.prisma—tb_user,tb_user_profile,tb_user_login_session, enums.tb_passwordwas removed in commitb2829da2(2026-05-17); credential storage and verification now live in the external identity provider. - Frontend:
../carmen-turborepo-frontend/apps/web/app/(app)/configuration/account/+ platform admin user-management. - carmen/docs:
../carmen/docs/workflow-permissions-system.md.
