¶ Delivery Point
At a Glance
Owner: Product Admin · Table:tb_delivery_point· Used by: PO, GRN, locations · Physical drop-off address for vendor deliveries.
¶ 1. What & Who
A delivery point is the physical address a vendor ships goods to — a loading dock, a back-of-house entrance, a remote-site receiving bay. POs carry the delivery point so the vendor knows where to drop; the GRN records the actual receiving point; and inventory locations can be tagged with a default delivery point so GRN routing has a sensible destination.
A property typically has a handful of delivery points (Main Dock, Banquet Dock, Spa Receiving) regardless of how many inventory locations exist downstream. Maintained by Product Admin; read by developers and testers on PO / GRN routing.
¶ 2. Common Tasks
| Task | Where | Notes |
|---|---|---|
| Add a delivery point | Configuration → Master Data → Delivery Point → New | Required: name |
| Deactivate | Toggle is_active |
Hidden from PO/GRN pickers; historical docs still resolve |
| Tag a location's default | master-data/location detail | Sets tb_location.delivery_point_id |
| Override on GRN | GRN header field | GRN inherits from PO but may override on receipt |
¶ 3. Validation & Errors
| Symptom / Message | Cause | Action |
|---|---|---|
| "Name already in use" | Duplicate name on a non-deleted row |
Pick a different name |
| "Name required" | Empty name |
Add a display name |
| "Cannot delete — referenced by POs / GRNs / locations" | FK references exist | Inactivate instead |
| Location shows stale delivery-point name | tb_location.delivery_point_name snapshot wasn't refreshed after rename |
Backfill via maintenance job |
¶ 4. Edge Cases
- Rename propagation. Documents store the FK so display refreshes automatically. Locations that snapshot the name (
tb_location.delivery_point_name) need a backfill if the rename must show on legacy lookups. - Inactivation hides from pickers but leaves historical references resolvable.
- No code field — only
nameis the identity here.
¶ 5. Data Model (Dev)
Source: tenant schema.
¶ 5.1 tb_delivery_point
| Field | Prisma Type | Nullable | Description |
|---|---|---|---|
id |
String @db.Uuid |
No | Primary key. |
name |
String @db.VarChar |
No | Display name (e.g. Main Dock). |
is_active |
Boolean? |
Yes | Active flag, defaults true. |
note, info, dimension |
— | Yes | Standard metadata. |
| Audit columns | — | Yes | created_*, updated_*, deleted_*. |
Constraints: @@unique([name, deleted_at]) map deliverypoint_name_u. Index on name. Reverse relations to tb_location, tb_purchase_request_detail, and PO-PR linkage tables.
¶ 6. Business Rules
- Uniqueness.
nameunique among non-deleted rows (DB-enforced). - Deletion guards. References from open POs, GRNs, or active locations block hard-delete.
- Validation.
namerequired. - Lifecycle. Inactive points stay readable on historical documents; hidden from pickers.
- Rename propagation. Documents resolve via FK; snapshotted name on
tb_locationneeds backfill.
¶ 7. Cross-References
- purchase-order — PO header carries delivery-point reference.
- good-receive-note — GRN inherits from PO, may override.
- master-data/location — each location can tag a default delivery point.
- purchase-request — PR detail may hold a delivery-point hint that propagates to PO.
¶ 8. References
- Prisma:
../carmen-turborepo-backend-v2/packages/prisma-shared-schema-tenant/prisma/schema.prisma—tb_delivery_point(lines ~623-646). - Frontend:
../carmen-turborepo-frontend/apps/web/app/(app)/configuration/delivery-point/.
