¶ Location
At a Glance
Owner: Product Admin · Table:tb_location· Used by: inventory, GRN, SR, physical count, spot check, PR/PO ·location_type(inventory/direct/consignment) decides posting behaviour.
¶ 1. What & Who
Locations are the physical or logical places where stock lives or is consumed — main warehouse, kitchen pass, bar, housekeeping cart, supplier-owned consignment shelf. The location_type field decides posting behaviour:
inventory— carries a stock balance, posts to inventory asset GL.direct— bypasses the balance, posts straight to department expense.consignment— holds supplier-owned goods, recognised only when consumed.
The same record configures period-end count behaviour (physical_count_type = yes / no) and the default delivery point that ships into this location. Maintained by Product Admin. Read by every inventory posting path.
¶ 2. Common Tasks
| Task | Where | Notes |
|---|---|---|
| Add a location | Configuration → Master Data → Location → New | Required: code, name, location_type |
| Tag default delivery point | Location detail | Sets delivery_point_id + denormalised delivery_point_name |
| Set count behaviour | Toggle physical_count_type |
no skips period-end count; spot check still applies |
| Deactivate | Toggle is_active |
Hidden from pickers; historical postings preserved |
Change location_type |
Edit dialog | Blocked after first movement — would corrupt journal history |
| Assign inventory tree | Location detail screen | Restricts which products are visible at this location |
¶ 3. Validation & Errors
| Symptom / Message | Cause | Action |
|---|---|---|
| "Code already in use" | Duplicate code among active rows |
Pick a different code |
| "Cannot delete — non-zero balance" | Location still holds stock | Issue out or transfer first |
| "Cannot delete — referenced by open SR/GRN" | FK references in open docs | Close documents first |
| "Cannot change location_type" | Edit attempted after first movement | Create a new location and migrate manually |
| Delivery-point name stale | delivery_point_name snapshot wasn't refreshed |
Re-save the location or run a backfill |
¶ 4. Edge Cases
location_typeis sticky once used — switchinginventory→directretro-actively corrupts journal entries.- Count exemption —
physical_count_type = noexcludes from period count but not from spot checks. - Consignment balances are supplier-owned; recognised on consumption rather than receipt.
- Delivery-point coupling —
delivery_point_nameis denormalised, needs refresh on rename. - Code uniqueness is app-enforced (no DB unique constraint).
¶ 5. Data Model (Dev)
Source: tenant schema.
¶ 5.1 tb_location
| Field | Prisma Type | Nullable | Description |
|---|---|---|---|
id |
String @db.Uuid |
No | Primary key. |
code |
String @db.VarChar |
No | Short code, e.g. INV1, KIT. |
name |
String @db.VarChar |
No | Display name. |
location_type |
enum_location_type |
No | inventory (default), direct, or consignment. |
description |
String? |
Yes | Free text. |
delivery_point_id |
String? @db.Uuid |
Yes | Optional FK to tb_delivery_point. |
delivery_point_name |
String? @db.VarChar |
Yes | Denormalised display copy. |
physical_count_type |
enum_physical_count_type |
No | no (default) — skip; yes — include. |
is_active |
Boolean? |
Yes | Active flag. |
note, info, dimension |
— | Yes | Standard metadata. |
| Audit columns | — | Yes | created_*, updated_*, deleted_*. |
Constraints: primary key on id. FK on delivery_point_id → tb_delivery_point onDelete: NoAction. Uniqueness on code enforced at app layer.
enum_location_type values: inventory, direct, consignment.
enum_physical_count_type values: no, yes.
¶ 6. Business Rules
- Uniqueness.
codeunique among active rows (app-enforced). - Deletion guards. Non-zero balance or open SR/GRN references block deletion.
- Validation.
location_typecannot change after first movement. - Lifecycle.
is_active = falsehides from pickers; preserves historical postings. - Count exemption.
physical_count_type = noexcludes period count, not spot check. - Delivery-point coupling. Refresh
delivery_point_namesnapshot on rename.
¶ 7. Cross-References
- inventory — every stock balance keyed by location; type decides whether balance is tracked.
- good-receive-note — GRN detail lines target a destination location; type drives the journal entry.
- store-requisition —
from_location/to_locationon every issue/transfer. - physical-count — counts scoped to locations with
physical_count_type = yes. - spot-check — sessions enumerate locations.
- purchase-request and purchase-order — detail lines may carry destination location.
¶ 8. References
- Prisma:
../carmen-turborepo-backend-v2/packages/prisma-shared-schema-tenant/prisma/schema.prisma—tb_location(lines ~1294-1393),enum_location_type(lines ~218-222),enum_physical_count_type(lines ~62-65). - Frontend:
../carmen-turborepo-frontend/apps/web/app/(app)/configuration/location/. - carmen/docs:
../carmen/docs/settings/locations.md— wireframes.
