¶ Vendor
At a Glance
Owner: Product Admin · Tables:tb_vendor,tb_vendor_address,tb_vendor_contact,tb_vendor_business_type· Used by: PR, PO, GRN, pricelist, RFQ · The supplier record — defaults tax profile, credit term, and currency onto procurement documents.
¶ 1. What & Who
Vendors are external counterparties the property buys from. The vendor record is the join point between procurement (PR → PO → GRN), the pricelist workflow (RFQ → pricelist → comparison), and accounting (tax profile, credit terms, payment). Four tables make up the entity: core tb_vendor (identity + tax linkage), multiple addresses in tb_vendor_address, multiple contacts in tb_vendor_contact, and a taxonomy of business types in tb_vendor_business_type.
The vendor record snapshots the tax profile at the vendor level so documents get sensible defaults that lines can still override. Maintained by Product Admin; read by every procurement and pricelist flow.
¶ 2. Common Tasks
| Task | Where | Notes |
|---|---|---|
| Add a vendor | Master Data → Vendor → New | Required: code, name; pick tax_profile_id and business types |
| Add address | Vendor detail → Addresses tab | At most one of each address_type per vendor |
| Add contact | Vendor detail → Contacts tab | One contact per vendor may be is_primary = true |
| Maintain business types | Master Data → Vendor Business Type | Separate list screen; references stored as JSON [{id, name}] on the vendor |
| Deactivate | Toggle is_active |
Hidden from new pickers; historical docs unchanged |
| Change tax profile | Edit dialog | Snapshots new tax_rate; does NOT retro-edit historical documents |
¶ 3. Validation & Errors
| Symptom / Message | Cause | Action |
|---|---|---|
| "Code/name already in use" | Duplicate (code, name) on a non-deleted row |
Pick different identifiers |
| "Address type already exists for this vendor" | Second address of same address_type attempted |
Edit the existing one instead |
| "Cannot delete — referenced by documents" | FK references from PR/PO/GRN/pricelist | Inactivate instead |
| "Vendor has no active contact" warning | All contacts inactive or deleted | Add or reactivate at least one contact |
| "Cannot have two primary contacts" | Two rows with is_primary = true |
Toggle off the old primary first |
¶ 4. Edge Cases
- Tax-profile change does not retro-edit existing documents; the snapshot on each line stays as posted.
- Business-type rename —
tb_vendor.business_typeJSON stores{id, name}array; vendors keep the old name until a maintenance job refreshes them. - Primary contact invariant is app-enforced, not DB.
- Address types —
contact_address,mailing_address,register_address; at most one of each per vendor. - Addresses/contacts soft-delete independently but each vendor should retain at least one active contact.
¶ 5. Data Model (Dev)
Source: tenant schema.
¶ 5.1 tb_vendor
| Field | Prisma Type | Nullable | Description |
|---|---|---|---|
id |
String @db.Uuid |
No | Primary key. |
code |
String @db.VarChar |
No | Short vendor code. |
name |
String @db.VarChar |
No | Display name. |
description |
String? @db.VarChar |
Yes | Free text. |
note |
String? @db.VarChar |
Yes | Internal note. |
business_type |
Json? @db.JsonB |
Yes | Array of {id, name} refs to tb_vendor_business_type (default []). |
tax_profile_id |
String? @db.Uuid |
Yes | Default tax profile for documents. |
tax_profile_name |
String? @db.VarChar |
Yes | Denormalised display copy. |
tax_rate |
Decimal? @db.Decimal(15, 5) |
Yes | Snapshotted rate at link time (default 0). |
is_active |
Boolean? |
Yes | Active flag. |
info, dimension |
Json? |
Yes | Standard metadata. |
| Audit columns | — | Yes | created_*, updated_*, deleted_*. |
Constraints: @@unique([code, name, deleted_at]) map vendor_code_name_u. Indexes on code, name, (code, name). FK to tb_tax_profile onDelete: NoAction.
¶ 5.2 tb_vendor_address
| Field | Prisma Type | Nullable | Description |
|---|---|---|---|
id |
String @db.Uuid |
No | Primary key. |
vendor_id |
String? @db.Uuid |
Yes | FK to tb_vendor. |
address_type |
enum_vendor_address_type? |
Yes | contact_address, mailing_address, or register_address. |
address_line1 |
String? @db.VarChar |
Yes | Street / house / soi. |
address_line2 |
String? @db.VarChar |
Yes | Building / floor. |
sub_district |
String? @db.VarChar |
Yes | Tambon / khwaeng. |
district |
String? @db.VarChar |
Yes | Amphoe / khet. |
city |
String? @db.VarChar |
Yes | For non-TH. |
province |
String? @db.VarChar |
Yes | Province / state. |
postal_code |
String? @db.VarChar |
Yes | ZIP / postcode. |
country |
String? @db.VarChar |
Yes | Country. |
is_active |
Boolean? |
Yes | Active flag. |
description, note, info, dimension |
— | Yes | Standard metadata. |
| Audit columns | — | Yes | created_*, updated_*, deleted_*. |
Constraints: @@unique([vendor_id, address_type, deleted_at]) — at most one of each address type per vendor. Indexes on (vendor_id, address_type) and vendor_id.
enum_vendor_address_type: contact_address, mailing_address, register_address.
¶ 5.3 tb_vendor_contact
| Field | Prisma Type | Nullable | Description |
|---|---|---|---|
id |
String @db.Uuid |
No | Primary key. |
vendor_id |
String? @db.Uuid |
Yes | FK to tb_vendor. |
name |
String @db.VarChar |
No | Contact person name. |
email |
String? @db.VarChar |
Yes | Email. |
phone |
String? @db.VarChar |
Yes | Phone. |
is_primary |
Boolean? |
Yes | Primary contact (default false). |
is_active |
Boolean? |
Yes | Active flag. |
description, note, info, dimension |
— | Yes | Standard metadata. |
| Audit columns | — | Yes | created_*, updated_*, deleted_*. |
Constraints: @@unique([vendor_id, name, deleted_at]). Indexes on (vendor_id, name) and vendor_id.
¶ 5.4 tb_vendor_business_type
Flat lookup — id, name, description, note, is_active, standard metadata, audit columns. App-enforced unique name among non-deleted rows.
¶ 6. Business Rules
- Uniqueness.
(code, name)unique among non-deleted vendors. At most one of eachaddress_typeper vendor. Contactnameunique within a vendor. - Deletion guards. Open PR/PO/GRN/pricelist references block hard-delete — inactivate.
- Validation.
codeandnamerequired.tax_ratesnapshotstb_tax_profileat link time. - Lifecycle.
is_active = falsehides from new pickers; existing documents keep working. Active vendor without active contacts should warn in UI. - Primary contact invariant. At most one
is_primary = trueper vendor (app invariant). - Tax-profile change propagation. Does not retro-edit documents; snapshots stay as posted.
- Business-type rename requires a maintenance job to refresh JSON snapshots on vendors.
¶ 7. Cross-References
- purchase-request — PR detail may suggest a preferred vendor.
- purchase-order — PO header binds a single vendor; FX, tax, credit terms default from here.
- good-receive-note — GRN inherits PO vendor.
- vendor-pricelist — pricelists and RFQ rounds scoped per vendor.
- master-data/tax-profile — vendor default tax profile.
- master-data/credit-term — vendor default credit term flows to PO header.
¶ 8. References
- Prisma:
../carmen-turborepo-backend-v2/packages/prisma-shared-schema-tenant/prisma/schema.prisma—tb_vendor(lines ~3249-3296),tb_vendor_address(lines ~3332-3365),tb_vendor_contact(lines ~3367-3396),tb_vendor_business_type(lines ~4853-…),enum_vendor_address_type(lines ~259-263). - Frontend:
../carmen-turborepo-frontend/apps/web/app/(app)/vendor-management/vendor/.
