¶ Email Configuration
At a Glance
Owner: Sysadmin only · Storage:tb_application_configrow (key = "report_email") · Used by:micro-notification, scheduled reports, password reset, audit alerts · One SMTP profile per BU; SMTP password encrypted at rest.
¶ 1. What & Who
Email Configuration is the per-BU SMTP profile Carmen uses for every outbound email — workflow notifications (PR / PO / GRN / SR approvals, sendbacks, rejections), scheduled report delivery, password-reset notices, and ad-hoc test emails. There is no dedicated table: the SMTP host, port, credentials, default-from, default-to / CC, and subject prefix all live as a single JSON blob in tb_application_config under the key report_email.
Audience: Sysadmin only (App ID app-config.upsert). No separate email-template table exists — bodies are built by micro-notification from per-notification-type templates; only subject_prefix (default [Carmen]) is user-tunable in the subject line.
¶ 2. Common Tasks
| Task | Where | Notes |
|---|---|---|
| Update SMTP host / port / username / from | System Admin → Email Configuration → SMTP Server section | Save calls PUT /api/config/:bu_code/app-config/report_email |
| Rotate SMTP password | Type the new password in the masked field, then Save | Encrypted at rest by encryptSecret; unchanged masked value = "leave password as-is" |
| Add / remove a default recipient or CC | Recipients section, comma-separated | Must be valid emails; Zod-validated on write |
| Change subject prefix | Recipients → Subject Prefix | Prepended to every subject (default [Carmen]) |
| Send a test email | Test Email button (top of form) | Uses the saved config, not the form draft — save first, then test |
| Silence email without breaking workflow | Set smtp.enabled = false |
Kill-switch: notifications short-circuit; documents still progress |
¶ 3. Validation & Errors
| Symptom / Message | Cause | Action |
|---|---|---|
| "Invalid SMTP config" Zod error | Missing host / username / from, or port outside 1..65535 |
Fill the required fields; check the port |
| "Recipient is not a valid email" | Bad address in recipients or cc |
Fix the comma-separated list |
| Test email succeeds in form but no mail arrives | Form draft not saved — Test uses the saved value | Click Save first, then Test Email |
| All notifications silent in production | smtp.enabled = false accidentally left set |
Re-enable on the form and Save |
| 403 on save / load | User lacks app-config.upsert (Sysadmin only) |
Grant via access-control/application-role |
Password field shows ***ENCRYPTED*** |
Expected — masked on read so ciphertext never reaches the browser | Leave as-is to keep current password; type new to rotate |
¶ 4. Edge Cases
- Password encryption at rest.
smtp.passwordis encrypted withencryptSecretbefore persistence and replaced with literal***ENCRYPTED***onGET. Idempotent — already-encrypted values are not re-encrypted. - Decrypted access path. Only the internal
getReportEmailForSend(bu_code)(TCP-only, called bymicro-notification/ cron) decrypts. The public HTTP path never returns plaintext. - Audit safety. Every upsert is captured via
EnrichAuditUsersinto reporting-audit/activity — but the value itself is not logged, avoiding accidental ciphertext disclosure. - One row per BU.
tb_application_confighas@@unique([key, deleted_at]). Cross-BU isolation is enforced by the BU-scoped route. enabledis a kill-switch, not a delete. Toggling off pauses email cleanly without losing the config.
¶ 5. Backing Service / Data Shape (Dev)
Source: tenant schema. No dedicated tb_email_config — the entire profile is one JSON row.
¶ 5.1 tb_application_config row (key = "report_email")
tb_application_config is the generic tenant-wide KV store (see system-config/application-config). The Zod-validated shape:
{
"smtp": {
"host": "smtp.gmail.com", // string, required
"port": 587, // int 1..65535
"username": "noreply@example.com", // string, required
"password": "ENC:<ciphertext>", // encrypted at rest; masked on GET
"from": "noreply@example.com", // From: header
"enabled": true // master kill-switch
},
"recipients": ["admin@example.com"], // default To
"cc": ["finance@example.com"], // default CC
"subject_prefix": "[Carmen]" // prepended to every subject
}
¶ 5.2 Related downstream tables
tb_report_schedule.recipients(JSONB) — per-schedule override.tb_report_job— actual send attempt (status,started_at,completed_at,error_message).tb_purchase_request.email_template_id,tb_purchase_order.email_template_id— string handle for the per-document template family inmicro-notification.
¶ 6. Business Rules
- Sysadmin-only. Read and write gated by App ID
app-config.upsert. - Password encryption + masking. Encrypted via
encryptSecret; replaced with***ENCRYPTED***on read. Unchanged masked value means "leave as-is". - Zod validation on write. Host, port (1–65535), username, password, from, enabled all required by
ReportEmailSchema;recipients/ccmust be valid emails. enabledkill-switch. Whenfalse, the notification service short-circuits before opening a connection — workflow still progresses, no email leaves.- Send context. Decryption only via internal
getReportEmailForSendover TCP frommicro-notification/ cron — no user_id required. - Test email uses the saved config (not the form draft) and goes to configured recipients.
- Audit logging via
EnrichAuditUsers; the JSON value itself is not logged.
¶ 7. Cross-References
- system-config/application-config — umbrella KV store;
report_emailis one reserved key. - reporting-audit/notification —
micro-notificationis the runtime consumer. - reporting-audit/schedule / reporting-audit/report — scheduled and on-demand report delivery.
- access-control/user — password reset, invite, access-grant emails.
- system-config/workflow — recipient routing rules (
requestor,current_approve,next_step) resolved against workflow; transport is this config. - reporting-audit/activity — upserts logged here.
¶ 8. References
- Prisma:
../carmen-turborepo-backend-v2/packages/prisma-shared-schema-tenant/prisma/schema.prisma—tb_application_config(lines ~4910-4924). - Backend service:
../carmen-turborepo-backend-v2/apps/micro-business/src/app-config/app-config.service.ts—ReportEmailSchema,encryptSensitiveFields,maskSensitiveFields,getReportEmailForSend,testEmail. - Backend gateway:
../carmen-turborepo-backend-v2/apps/backend-gateway/src/config/config_app-config/config_app-config.controller.ts. - Frontend route:
../carmen-inventory-frontend/app/(root)/system-admin/config-email/page.tsxand_components/config-email-component.tsx. - Frontend hook:
../carmen-inventory-frontend/hooks/use-app-config.ts—useAppConfigByKey('report_email'),useUpsertAppConfig,useTestEmail. - Notification consumer:
micro-notificationreads via TCP fromgetReportEmailForSend.
